PRODUCT FEATURES
- Pulse width, duty cycle, Min/Max/Avg recording
- 10 meg ohm input impedance won?t damage computer circuits
- Large display and bright backlight for increased visibility
SPECIFICATIONS
DCV
Maximum voltage: 1000 V
Accuracy: ?(0.1% + 1)
Best resolution: 0.01 mV
ACV
Maximum voltage: 1000 V
Accuracy: ?(0.5% + 2)
AC bandwidth: 5 kHz
Best resolution: 0.01 mV
DC current
Maximum amps: 10 A
Amps accuracy: ?(0.4 % + 2)
Best resolution: 0.001 mA
AC current
Maximum amps: 10 A
Amps accuracy: ?(1.2% + 2)
Best resolution: 0.001 mA
Resistance
Maximum resistance: 50 M?
Accuracy: ?(0.4% + 1)
Best resolution: 0.1 ?
Capacitance
Maximum capacitance: 9,999 ?F
Accuracy: ?(1% + 2)
Best resolution: 0.01 nF
Frequency
Maximum frequency: 200 KHz
Accuracy: ?(0.005% + 1)
Best resolution: 0.01 Hz
Duty cycle
Maximum duty cycle: 99.9%
Accuracy: within 2% per KHz + 0.1%
Best resolution: 0.1%
Temperature measurement: 200.0?C ? 1090?C, -328.0?F ? 1994.0?F, 1.0% excluding probe
80 BK temperature probe: -40 ?C ? 260?C, -40 ?F ? 500?F, 2.2?C or 2% whichever is greater
Conductance
Maximum conductance: 60.00 nS
Accuracy: ?(1.0% + 10)
Maximum resolution: 0.01 nS
Operating range
Operating temperature: -20?C ? 55?C
Storage temperature: -40?C ? 60?C
Physical: 5.2 x 9.8x 20.1 cm (2.06 x 3.86 x 7.93 in), 624 g (22 oz.)
