PRODUCT FEATURES
- Compact and lightweight in size: The product is sturdy and durable, with a size only 4/5 of the size of the iPhone 15, suitable for one handed grip operation
- One-click shortcut operation: Support one click mute, one click pump on/off (E410P), convenient operation effectively improves work efficiency
- Multiple detection principles: Support various sensors such as infrared, electrochemical and PID, which can meet more than 10 gas detection needs
- Long-life O2 sensor: Support O2 sensor with a service life of 5 years, effectively reducing the risk of leakage
- Up to 5-gas detection: Supports dual-sensor (CO and H2S), which can meet customers' needs for simultaneously detecting five types of gases
- Multiple wireless signal: Support Bluetooth / 4G networking mode, paired with a mobile app for convenient remote real-time monitoring
- Large LCD screen display: Equipped with a 2.5-inch LCD screen with built-in high brightness backlight for more intuitive information display
- Easy to operate and learn: 4- button design and simple and easy to learn interactive logic enable users to operate in a "foolproof" manner beyond the user manual
- Long endurance working time: Large capacity lithium batteries meet the requirements of long endurance work, with E410 endurance time >= 14h and E410P >= 12h
- Advanced temperature compensation algorithm: When the temperature of the sensor changes, it can automatically compensate and improve the accuracy and reliability of gas detection.
APPLICATIONS
- Petroleum and Petrochemicals
- Emergency rescue
- Offshore platform
- Pharmaceutical and Chemical Industry
- Industrial waste gas
- Incineration power generation
SPECIFICATIONS
Sampling method: Diffusion type E410 / Pumped type E410P
Detection principle: Infrared, electrochemical, PID etc.
Sensor channel: 4
Working time (full charge): E410>=14h, E410P>=12h
Explosive proof: Ex ib IIC T4 Gb / Ex ib IIIC T130?C Db
Ingress protection: E410: IP67, E410P:IP66
Indication method: LCD displays real-time data and detector status
Visual / audible / vibrative alarming signals for gas leakage, low battery voltage, over range, sensor fault etc.
Dimension: 122.5(H)x 68(W)x 30.5(D)mm
Weight: E410 204g, E410P 228g
Ambient environment: Temp.: -20~55?C? ?Humidity: <95%RH
Pressure: 90kPa~110kPa
