PRODUCT FEATURES
- Choose the thermal camera that gives you in-focus images in a matter of seconds. LaserSharp? Auto Focus uses a built-in laser distance meter that calculates and displays the distance from your designated target and immediately adjusts the focus.
- See small details in the image and discover anomalies faster with 640 x 480 resolution thermal images
- On the thermal camera, adjust the level of infrared and visible light with patented IR-Fusion? technology
- Manage data, capture multiple measurements (mechanical, electrical and thermal) and organize them by piece of equipment with Fluke Connect? software
- Simply the best optics to transmit energy and produce high quality infrared images. Fluke thermal cameras use only 100% diamond-turned germanium lenses with specialty coatings.
- Subject to Export Control
SPECIFICATIONS
Color alarms (temperature alarms): High temperature, low temperature, and isotherms (within range)
Infrared spectral band: 7.5 um to 14 um (long wave)
Operating temperature: -10 ?C to +50 ?C (+14 ?F to +122 ?F)
Storage temperature: -20 ?C to +50 ?C (-4 ?F to +122 ?F)
Relative humidity: 10 % to 95 % non-condensing
Center-point temperature measurement: Yes
Spot temperature: Hot and cold spot markers
User-definable spot markers: No
User defined measurement boxes: 1 expandable-contractible measurement box with MIN-MAX-AVG temp display
Hard Case: Rugged, hard carrying case; soft transport bag
Safety: IEC 61010-1: Overvoltage category II, Pollution Degree 2
Electromagnetic compatibility: IEC 61326-1: Basic EM environment. CISPR 11: Group 1, Class A
Australian RCM: IEC 61326-1
US FCC: CFR 47, Part 15 Subpart B
Vibration: 0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6
Shock: 25 g, IEC 68-2-29
Drop: Engineered to withstand 2 meter (6.5 feet) drop with standard lens
Size (H x W x L): 27.7 x 12.2 x 16.7 cm (10.9 x 4.8 x 6.5 in)
Weight (battery included): 1.04 kg (2.3 lb)
Enclosure rating: IEC 60529: IP54 (protected against dust, limited ingress; protection against water spray from all directions)
Warranty: Two-years (standard), extended warranties are available
Recommended calibration cycle: Two-years (assumes normal operation and normal aging)
Supported languages: Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
RoHS compliant: Yes
