Centurion FS-006 Explosion-Proof Safety Hand Lamp Stacking Stand

Explosion-Proof Safety Hand Lamp Stacking Stand

Model: FS-006

Technical Detail:

The Flood Light Stands FS-006 accommodate the 6 pieces Centurion EX-6100 Safety Hand Lamps and exploit their excellent performance and reliability to collectively deliver a flood of outstanding illumination of up to 968 lumens.

The Safety Hand Lamp EX-6100 is ATEX approval for use in Zones 0,1 & 2 potentially explosive gas atmospheres and Zones 20, 21 & 22 potentially explosive dust atmospheres. Group I approval for use in mining applications.

Ex Mark: I M1 Ex ia I Ma

              II 1G Ex ia op is IIC T4 Ga

              II 1D Ex ia IIIC T135°C Da

For more details about the EX-6100, please refer to its product page:

EX-6100 ATEX Intrinsically Safe Safety Hand Lamp

The FS-006 stand is made of stainless steel with an Anti-static coating; each frame incorporates hand lamp holders with a "snap-in/snatch-out" function to secure the hand lamp but quick release and allows the flood light stand of hand lamps to be manually tilted and locked in position. The hand lamps can be removed from the stand in the hazardous area and used for close inspection work or in awkward to reach locations.

The stand is easily transportable for maintenance tasks using the handle, plus the easy single-handed switching of the hand lamps, even with gloved hands. In addition, the flood stacking stand can be placed on level ground or mounted on a tripod (available separately) to elevate, direct and focus the light to the desired task working area.

-   Areas of Classification (Gases): Zone 0, 1 and 2, Gas Groups: IIA, IIB, and IIC

-   Areas of Classification (Dusts): Zone 20, 21, and 22, Dust Groups: IIIA, IIIB, and IIIC

-   Hand Lamp Configuration: 6 pieces of EX-6100 Safety Hand Lamp

-   Single Hand Lamp Output: Up to 242 Lumens (effective lumens)

-   Total Output: Up to 1452 Lumens (effective lumens)

-   Light Duration: Up to 28.3 Hours

-   Hand Lamp’s Ingress Protection: IP66

-   Single Hand Lamp Power Source: 4 x LR20(D) Alkaline Battery

-   Flood Light Stand Material: 304 Stainless Steel with Anti-static coating

-   Hand Lamp Holder Material: Polypropylene (anti-static), "Snap-in/Snap-out" Function

-   Stand Dimension (length x width x height): 370*510*522mm

-   Weight-Stand only: 7.0kg

-   Weight-Carrying in Work: +/-14.60kg (1 piece of hand lamp flood light stand + 6 pieces of EX-6100 with batteries)

-   Packing: 1 piece of hand lamp flood light stand + 6 pieces of EX-6100 (batteries not included), total net weight +/-12.70kg
