The simplified ARPA function helps to prevent a collision risk with other vessels or objects. Up to five targets can be automatically tracked on the radar echo, when a target enters within the set watch area, (or up to ten targets can be tracked when manually set). By selecting one of the targets, the target information such as position, course, speed, CPA, TCPA, bearing, and distance is shown on the lower side of the display. When the target enters within the CPA and TCPA limits, an alarm message is displayed with a beep alarm.
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
Display type: 10.4-inch Color TFT LCD
Resolution: 480 × 640 dots
Minimum range: 25 m; 82 ft (at 1⁄8 NM range)
Maximum range: 36 NM
Range scales
NM: 1⁄8, 1⁄4, 1⁄2, 3⁄4, 1, 1.5, 2, 3, 4,
6, 8, 12, 16, 24, 32, 36
km: 1⁄4, 1⁄2, 3⁄4, 1, 1.5, 2, 3, 4,
6, 8, 12, 16, 24, 32, 36, 48
Preheat time: 90 seconds
Power supply: 10.2–42 V DC
Power consumption(at zero wind velocity): 55 W (approximately)
Usable temperature range: −15°C to +55°C; +5°F to +131°F
Input data format: NMEA 0183, N+1, AUX, IEC61162-2
Output data format: NMEA 0183
